MU117.0625.16
Material number MU117062516
HORN Toolholders MU117.0625.16 for Turning
tool-application
static
tightening_torque
6 Nm
semi-finished-insert
S117.0014/16.00
size
16
cutting-width-max-imp
0.63 ˝
16 mm
cutting-width-imp
0.63 ˝
16 mm
shank-width-met
0.625 ˝
15.875 mm
peak-height-imp
0.625 ˝
15.875 mm
insertion-depth-max-imp
0.197 ˝
5 mm
shank-height-imp
0.625 ˝
15.875 mm
total-length-including-cutting-insert-imp
4.921 ˝
125 mm
adjustment-dimension-imp
0.236 ˝
6 mm
