CCGT120408N.HN PD70
Material number CCGT120408NHNPD70
HORN Inserts CCGT120408N.HN PD70 for Turning
Effective cutting length (l1)
0.138 ˝
3.5 mm
us-cutting
Yes
cutting
1
tool-application
static
Inner circle diameter (d)
0.5 ˝
12.7 mm
Bore diameter (d2)
0.217 ˝
5.5 mm
Cutting insert height, Cutting insert thickness (s)
0.187 ˝
4.76 mm
Corner radius (r)
0.031 ˝
0.8 mm
