BKT105.1732.00.01.IK
Back working holder for HORN insert type 105
Material number BKT10517320001IK
HORN Back working holder for HORN insert type 105 BKT105.1732.00.01.IK for Turning
Bore diameter rotate (h)
1.26
˝
32
mm
Total length (l1)
0.945
˝
24
mm
neck-diameter-imp
0.787
˝
20
mm
Katalog_CCTMS
Kerbverzahnung 60° / T3
Katalog_CCTWS
105123;105124;105125
DIN_CCTWS
HORN-10512395N;HORN-10512495N;HORN-10512595N
ISO_CCTWS
HORN105123$95N$$$$$;HORN105124$95N$$$$$;HORN105125$95N$$$$$
Width (b)
0.669
˝
17
mm
Outcropping, neck, working length (l3)
0.472
˝
12
mm
| Downloads | |
|---|---|
| BKT10517320001IK_20230112_174107144.STP | Download |
| BKT10517320001IK.DXF | Download |
| Download all files | |
